FESTO 151687 MSSD-EB PLUG SOCKET
Quick Overview
Manufactured By: FESTO
Manufacturer Part Number: 151687
IMS Product Code: 2129440
Packaging: Sold Individually
Description:
Festo 151687 MSSD-EB Plug Socket
3-Pin Type C plug socket for solenoid coils and valves, 6-8 mm cable diameter, IP65 protection, -45 to 90 degrees C operating temperature
Specifications
- Type: 3-Pin Type C
- Series: MSSD
- Cable Size: 6 to 8 mm
- Length: 30 mm
- Shell Material: Plastic
- Ambient Temperature: -45 degrees C ... 90 degrees C
- Degree of Protection: IP65
- Operational Voltage Range AC: 0 V ... 250 V
- Operational Voltage Range DC: 0 V ... 300 V
- Current Rating: 6 A
- Immunity to Surge: 4 kV
- Mounting Type: On solenoid valve via M2.5 central screw
- Cable Outlet: Angled, 90 degrees rotatable
- Material Housing: Polymer
- Material Seals: NBR
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 6 hours and 54 minutes.
