KEYENCE FS-N15CN FIBER AMPLIFIER
Quick Overview
Manufactured By: KEYENCE
Manufacturer Part Number: FS-N15CN
IMS Product Code: 2159037
Packaging: Sold Individually
Description:
Keyence FS-N15CN Fiber Amplifier
IP66 Fiberoptic Amplifier with M8 connector, NPN output, 12-24 VDC power supply
Specifications
- Output: NPN open collector, 24 V or less, 100 mA or less
- Response Time: 50 µs (HIGH SPEED) to 16 ms (MEGA)
- Power Voltage: 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less
- Current Consumption: Normal: 900 mW or less, Eco on mode: 800 mW or less, Eco Full mode: 470 mW or less
- Enclosure Rating: IP66
- Ambient Temperature: -20 to +55 °C
- Material: Glass-reinforced PBT
- Weight: Approx. 30 g
- I/O Format: M8 connector
- Main Unit/Expansion Unit: Main unit
- Timer Function: Timer OFF/OFF delay/ON delay/One-shot
- Light Source LED: Red 4-element LED (wavelength 630 nm)
- Protection Circuit: Reverse polarity protection, Over-current protection, Surge absorber
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships on Tuesday, May 26, 2026
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
