AMI BEARINGS UCP210 PILLOW BLOCK BEARING
Quick Overview
Manufactured By: AMI BEARINGS
Manufacturer Part Number: UCP210
IMS Product Code: 1873945
Packaging: Sold Individually
Description:
Ami Bearings UCP210 Pillow Block Bearing
Pillow Block Ball Bearing Unit - 2-Bolt Base, 50 mm Bore, Cast Iron Material, Standard Duty, Non-Expansion Bearing (Fixed)
Specifications
- Shaft Diameter: 50 mm
- Bolt Size: M16
- Bearing: UC210
- Housing: P210T
- Lubrication Fitting Tap: 1/8-27 NPT
- Weight: 6.02 lb
- Mounting Type: 2-Bolt Base
- Bore Type: Round
- Bore Diameter: 50 mm
- Bolt Center To Center Length: 149 mm to 168 mm
- Base To Bore Centerline: 57.20 mm
- Duty Type: Standard Duty
- Locking Device: Set Screw
- Seal Type: Contact with Slinger
- Housing Material: Cast Iron
- Expansion Type: Non-Expansion Bearing (Fixed)
- Overall Height: 114 mm
- Overall Length: 206 mm
- Base Width: 60 mm
- Radial Dynamic Load Capacity: 3600 kgf
- Radial Static Load Capacity: 2370 kgf
- Lubrication Type: Lubrication Fitting
- Series: UCP200
- Locking Type: Set Screw
- Number Of Mounting Holes: 2
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 6 In Stock
Ships today if ordered in the next 3 hours and 42 minutes.
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 3 hours and 42 minutes.
