IFM AL1320 IO-LINK MASTER
Quick Overview
Manufactured By: IFM
Manufacturer Part Number: AL1320
IMS Product Code: 2014963
Packaging: Sold Individually
Description:
Ifm AL1320 IO-Link Master
IO-Link master with EtherNet/IP interface
Specifications
- Application: I/O modules for field applications
- Daisy-chain function: fieldbus interface
- Operating voltage [V]: 20...30 DC
- Current consumption [mA]: 300...3900
- Protection class: III
- Max. current load total [A]: 3.6
- Total number of inputs and outputs: 8
- Number of digital inputs: 8
- Number of digital outputs: 4
- Switching level high [V]: 11...30
- Switching level low [V]: 0...5
- Max. current load per output [mA]: 300
- Communication interface: Ethernet; IO-Link
- Transmission standard: 10Base-T; 100Base-TX
- Transmission rate: 10 MBit/s; 100 MBit/s
- Protocol: EtherNet/IP; MQTT JSON
- IO-Link revision: 1.1
- Number of ports class A: 4
- Ambient temperature [C]: -25...60
- Storage temperature [C]: -25...85
- Max. relative air humidity [%]: 90
- Protection: IP 65; IP 66; IP 67
- Protection rating (NEMA 250): 6P
- Degree of soiling: 2
- MTTF [years]: 95
- Weight [g]: 306.75
- Material: housing: PA orange; Socket: brass nickel-plated
- Sealing material: FKM
