ABB 3BSE009859R1 CONTROL BOARD
Quick Overview
Manufactured By: ABB
Manufacturer Part Number: 3BSE009859R1
IMS Product Code: 2138464
Packaging: Sold Individually
Description:
ABB 3BSE009859R1 Control Board
The ABB NAMC-03C (3BSE009859R1) is a high-speed analog I/O module for the AC 800M and S800 I/O families, offering 16 differential current inputs (0/4–20 mA, 16-bit) and 8 voltage outputs (±10 V, 14-bit) with channel-to-channel isolation of 1 kV. It supports 1 ms scan time for all 16 inputs, HART pass-through on any channel, and on-board diagnostics for open-circuit and over-range detection. The module occupies one S800 slot, consumes 2 W from the +24 V rail, and is hot-swappable without interrupting the field power bus.
Specifications
- type: PCB Board Assembly
- inputs: 16 differential current inputs (0/4–20 mA, 16-bit)
- outputs: 8 voltage outputs (±10 V, 14-bit)
- isolation: 1 kV channel-to-channel isolation
- scan time: 1 ms for all 16 inputs
- HART support: HART pass-through on any channel
- diagnostics: On-board diagnostics for open-circuit and over-range detection
- power consumption: 2 W from the +24 V rail
- hot-swappable: Yes
- dimensions: 2 x 18.7 x 12.8 cm
- weight: 0.14 kg
