AIRGUARD 0450200 DP MAX PLEATED FILTER
Quick Overview
Manufactured By: AIRGUARD
Manufacturer Part Number: 0450200
IMS Product Code: 2146993
Packaging: Box of 12
Description:
Airguard 0450200 DP Max Pleated Filter
Pleated air filter with MERV 8 rating, 12x24x2 inches nominal size, made of moisture-resistant beverage board frame and galvanized steel support grid.
Specifications
- Actual Filter Size: 11 3/8 x 23 3/8 x 1 3/4 inches (289 x 594 x 44mm)
- Adhesive Type: Water Repellent Adhesive
- Air Flow Rates: 210–3,640 cfm
- Dimensions: 12 x 24 x 2 inches
- Efficiency: 25 - 30%
- Final Resistance: 1.0 in.w.g.
- Filtration Efficiency: MERV 8
- Frame Construction: Two Piece
- Frame Material: Heavy Duty Beverage Board
- Initial Resistances: 0.16–0.21 in.w.g.
- Material of Construction: moisture-resistant beverage board frame; rust-resistant, expanded metal support grid made of galvanized steel
- Maximum Operating Temperatures: 225 degrees F (107 degrees C)
- MERV Rating: 8
- Nominal Filter Size: 12x24x2
- Number in Pack: 12
- Pleat Support Material: Galvanized Steel
- Pleats Per Foot: 10
- Rated Air Velocity: 300–625 fpm
- Type: Pleated
