ALLEN BRADLEY 1764-24BWA MICROLOGIX 1500 BASE UNIT
Quick Overview
Manufactured By: ALLEN BRADLEY
Manufacturer Part Number: 1764-24BWA
IMS Product Code: 148078
Variation: Unspecified
Unspecified
Series: A
Series: B
Packaging: Sold Individually
Description:
Allen Bradley 1764-24BWA MicroLogix 1500 Base Unit
MicroLogix 1500 base unit with 85-265 VAC line power voltage, 8 x 24VDC sink/source discrete inputs, 4 high-speed inputs, and 12 relay outputs. It features integrated RS232 communication ports.
Specifications
- Line Power Voltage: 85-265 VAC
- Discrete Inputs: Eight (8) 24VDC sink/source
- High Speed Inputs: Four (4)
- Relay Outputs: Twelve (12)
- Depth: 87 mm
- Height: 138 mm
- Input Signal: 24V DC
- Interface: RS-232C Port
- Output Signal: Relay
- Dimensions (LxWxH): 13 x 5 x 3 in.
- Weight: 0.41 kgs
- Mounting Style: Din Rail Mount
- Terminal Style: Screw Terminals
