AMI UCF209-28C4HR23 4-BOLT FLANGE BEARING UNIT
Quick Overview
Manufactured By: AMI BEARINGS
Manufacturer Part Number: UCF209-28C4HR23
IMS Product Code: 1833698
Packaging: Sold Individually
Description:
Ami UCF209-28C4HR23 4-Bolt Flange Bearing Unit
Four-bolt flange ball bearing unit with 1-3/4 inch bore diameter, cast iron housing, and set screw locking.
Specifications
- Bore Diameter: 1-3/4 in
- Housing Material: Cast Iron
- Duty Type: Standard Duty
- Bolt Center To Center Length: 4.1250 in
- Locking Device: Set Screw
- Bearing Insert Material: Bearing Steel
- Expansion Type: Non-Expansion Bearing (Fixed)
- Seal Type: Contact Seal with Flinger
- Bore Type: Straight
- Lubrication Type: Relubricatable
- Radial Dynamic Load Capacity: 7420 lbf
- Radial Static Load Capacity: 4610 lbf
- Length Through Bore: 1.937 in
- Series: UCF200C4HR23
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships on Monday, January 26, 2026
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships on Monday, January 26, 2026
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
