AMI BEARINGS UCP307 PILLOW BLOCK BEARING
Quick Overview
Manufactured By: AMI BEARINGS
Manufacturer Part Number: UCP307
IMS Product Code: 2136435
Packaging: Sold Individually
Description:
Ami Bearings UCP307 Pillow Block Bearing
Pillow Block Ball Bearing Unit - 2-Bolt Base, 35 mm Bore, Cast Iron Material, Heavy Duty, Non-Expansion Bearing (Fixed)
Specifications
- Shaft Diameter: 35 mm
- Bolt Size: M14
- Bearing: UC307
- Housing: P307
- Lubrication Fitting Tap: 1/8-27 NPT
- Weight: 6.06 lb
- Mounting Type: 2-Bolt Base
- Bore Type: Round
- Bore Diameter: 35 mm
- Bolt Center To Center Length: 146 mm to 172 mm
- Base To Bore Centerline: 56 mm
- Duty Type: Heavy Duty
- Locking Device: Set Screw
- Seal Type: Contact with Slinger
- Housing Material: Cast Iron
- Expansion Type: Non-Expansion Bearing (Fixed)
- Overall Height: 105 mm
- Overall Length: 210 mm
- Base Width: 56 mm
- Overall Width: 57 mm
- Radial Dynamic Load Capacity: 3400 kgf
- Radial Static Load Capacity: 1960 kgf
- Lubrication Type: Lubrication Fitting
- Series: UCP300
- Replacement Bearing: UC307
- Locking Type: Set Screw
- Number Of Mounting Holes: 2
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 1 hours and 56 minutes.
