ASCO 8221G011 SOLENOID VALVE
Quick Overview
Manufactured By: ASCO
Manufacturer Part Number: 8221G011
IMS Product Code: 2145605
Packaging: Sold Individually
Description:
Asco 8221G011 Solenoid Valve
2-Way Normally Closed Solenoid Valve with Brass Body and Buna N Elastomer Seals. 1-1/2" Pipe Size, 1-1/4" Orifice, Cv=24.
Specifications
- Type: Solenoid Valve
- Operation: 2-way
- Connection: 1-1/2" NPT
- Normal State: Normally Closed
- Service: Slow Closing Service
- Body Material: Brass
- Voltage: 120/60 VAC, 110/50 VAC, 24 VDC
- Max Media Temperature: 180°F
- Media Compatibility: Water
- Orifice Size: 1-1/4 in
- Cv: 24
- Pipe Size: 1-1/2 in
- Wetted Materials: Brass, Buna N
- Pressure Range: 5 - 150 PSI
- Seal Material: Buna N Elastomer
- Enclosure Rating: NEMA 1, NEMA 2, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X
- Coil Insulation Class: Class F
- Wattage: 6.1 W
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 6 hours and 17 minutes.
