ASHCROFT 60-1379 PRESSURE GAUGE
Quick Overview
Manufactured By: ASHCROFT
Manufacturer Part Number: 60-1379-WWSL-09B-80000#
IMS Product Code: 2131300
Packaging: Sold Individually
Description:
Ashcroft 60-1379 Pressure Gauge
Pressure gauge with 6-inch aluminum dial, Inconel 718 Bourdon tube, and black epoxy coated aluminum case. It has a pressure range of 0 to 80,000 psi and an accuracy of ±0.5%.
Specifications
- Connection Location: Back Mount
- Dial Material: Aluminum
- Dial Size: 6 in.
- Display Type: Dial
- Enclosure Material: Epoxy Coated Rugged Aluminum
- Full-Scale Accuracy: ± 0.5%
- Max. Pressure: 80000 psi
- Min. Pressure: 0 psi
- Mounting Type: Stem/Surface/Flush
- Pointer Material: Aluminum
- Pointer Type: Micrometer Adjustable
- Product Family: 1379
- Sensor Element: Inconel 718 Bourdon Tube/Socket
- Temperature Rating: -20 to 250 degrees F (Ambient), -20 to 250 degrees F (Process), -40 to 250 degrees F (Storage)
- Connection Size: 9/16 in.
- Enclosure Color: Black
- Filled: Dry
- Connection Type: UNF
- Case: Black Epoxy Coated Aluminum
- Pressure Range: 0 to 80,000 psi
