ATLAS COPCO 8411101055 VANE MOTOR
Quick Overview
Manufactured By: ATLAS COPCO
Manufacturer Part Number: 8411101055
IMS Product Code: 2149059
Packaging: Sold Individually
Description:
Atlas Copco 8411101055 Vane Motor
Vane motor with six vanes and optimum cylinder sealing for rugged, compact design. Keyed shaft, lubrication-free vanes, reversible rotation.
Specifications
- Air consumption at max output: 78 cfm
- Ingress protection rating: IP66
- Max output: 1.7 hp
- Speed at max output: 4300 r/min
- External parts material: Powder coated cast iron/Aluminium
- Free speed: 9000 r/min
- Inlet hose size: 0.5 in
- Outlet hose size: 1 in
- Weight: 10.8 lb
- Built in brake: No
- Rotation direction: Reversible
- Shaft type: Keyed
- Vane type: Lubrication free
- Min starting torque: 3.5 ft-lb
- Stall torque: 4.3 ft-lb
- Torque at max output: 2.1 ft-lb
- ATEX code dust: Ex II 2 D Ex h IIIC T85°C Db X
- ATEX code gas: Ex II 2 G Ex h IIC T6 Gb X
- ATEX: Yes
- ATEX Max Temperature: 85 degrees C
- ATEX Technical file: 9836 4610 00
