ATLAS COPCO LZB14-L-A007-11 VANE AIR MOTOR
Quick Overview
Manufactured By: ATLAS COPCO
Manufacturer Part Number: LZB14-L-A007-11
IMS Product Code: 2126497
Packaging: Sold Individually
Description:
Atlas Copco LZB14-L-A007-11 Vane Air Motor
Atlas Copco LZB vane motors utilize five vanes to ensure excellent starting and low speed performance. Most models come in standard and stainless-steel versions. The long and slim design integrates with various mounting styles while multi-step planetary gears provide exact torque and speed requirements.
Specifications
- Speed: 700 r/min
- Air consumption at max output: 4 l/s
- Max working pressure: 7 bar
- ATEX code dust: Ex II 2 D Ex h IIIC T85°C Db
- ATEX code gas: Ex II 2 G Ex h IIC T6 Gb
- ATEX: Yes
- ATEX Max Temperature: 85 °C
- ATEX Technical file: 9836 4610 00
- Ingress protection rating: IP66
- Max ambient temperature: 40 °C
- Built in brake: No
- Rotation direction: Clockwise
- Shaft type: Keyed
- Vane type: Lubrication free
- Inlet hose size: 8 mm
- Outlet hose size: 8 mm
- Weight: 0.33 kg
- External parts material: Hardened steel/Aluminium
- Max output: 0.16 kW
- Speed at max output: 320 r/min
- Min starting torque: 8.5 Nm
- Stall torque: 9.6 Nm
- Torque at max output: 4.8 Nm
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 52 minutes.
