ATLAS SOUND GD87W 8" CEILING SPEAKER
Quick Overview
Manufactured By: ATLAS SOUND
Manufacturer Part Number: GD87W
IMS Product Code: 1745935
Packaging: Sold Individually
Description:
Atlas Sound GD87W 8" Ceiling Speaker
Passive, non-shielded 8" ceiling speaker with 8W multi-tap transformer for voice amplification and background music.
Specifications
- Active or Passive: Passive
- Power Handling: RMS: 16 W, Peak: 25 W
- Low Frequency Driver: 8" Treated Paper with 1" Voice Coil
- High Frequency Driver: 3"
- Frequency Response: 45 Hz to 19 kHz
- Coverage: 120°
- Nominal Sensitivity: 96 dB
- Nominal Impedance: 8 Ohms
- Power Taps: 1, 2, 4, 8 Watts
- Crossover: 2.8 kHz
- Maximum Insertion Loss: 0.6 dB
- Shielded: No
- Input Connections: 6" Color-Coded Wire Lead
- Safety Rating: UL 1480 and UL 2043
- Basket Materials: Stamped, Plated 20-Gauge CRS
- Mounting Pattern: Speaker: 7.6", Baffle: 11.3"
- Dimensions: 12.8 x 2.9"
- Weight: 2 lb
