AXIS 01190-001 CONDUIT BACK BOX
Quick Overview
Manufactured By: AXIS
Manufacturer Part Number: 01190-001
IMS Product Code: 2143726
Packaging: Sold Individually
Description:
Axis 01190-001 Conduit Back Box
Outdoor-ready, impact-resistant back box for Axis network cameras, with ingress-protected compartment for connectivity devices.
Specifications
- Mounting: Camera Mount
- Cable Routing: 0.75" / 19 mm Opening, Back: 3x cable holes, Sides: 3/4" conduit entrances, Underside: 4x gaskets C M20 5-9.5mm, Top Cover: 3x gaskets C M20 5-9.5mm
- Load Capacity: 5 lb / 2.3 kg, 5 lbs
- Color: White
- Impact Resistance: Impact-Resistant (IK10), IK10+
- Certifications: IEC 60068-2-6, IEC 60068-2-27, IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, NEMA 4X
- Materials: Aluminum, Stainless Steel
- Diameter: 6.18" / 157 mm
- Height: 2.1" / 53.5 mm
- Weight: 1.65 lb / 750 g
- Model: T94S01P
- MPN: 01190-001
- Installation Location: indoor, outdoor
- Compatibility: AXIS P3245, M3057, M3058, M3215, M4308, P3228, P3255, P3374, P3375, Q3515, Q3517
- Mount Type: Back Box
- Environmental: Outdoor
- IP Rating: IP66/IP67
- Conduit Interface: ¾" / M25
- Mounting: Double gang box, Single gang box, 4" octagon junction box, 4" square junction box
- Durability Ratings: IP66/67, IK10+, NEMA 250 Type 4X
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 3 hours and 20 minutes.
