AZBIL FL2R-4J6SD SQUARE PROXIMITY SWITCH
Quick Overview
Manufactured By: AZBIL
Manufacturer Part Number: FL2R-4J6SD
IMS Product Code: 1938377
Packaging: Sold Individually
Description:
Azbil FL2R-4J6SD Square Proximity Switch
DC 2-Wire Square Proximity Sensor with 4mm sensing distance, 1m cable, side sensing face, NO output
Specifications
- Type: Proximity Sensor Square
- Wire Configuration: DC 2 Wire
- Dimensions: 15x15x32
- Sensing Face: Side
- Output: NO
- Sensing Distance: 4mm
- Cable Length: 1 m
- Termination: preleaded
- Operating Temperature Range: -25 to +70 degrees C
- Insulation Resistance: 50 MOhm min. (at 500 Vdc)
- Dielectric Strength: 500 Vac, 50/60 Hz for 1 minute
- Vibration Resistance: 10 to 55 Hz, 1.5 mm peak-to-peak amplitude, 2 hrs each in X, Y, and Z directions
- Shock Resistance: 490 m/s^2 10 times each in X, Y, and Z directions
- Protection: IP67
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 4 In Stock
Ships Tomorrow
