BALDOR VENM3542 GENERAL PURPOSE MOTOR

Call For Quote

Quick Overview

Manufactured By: BALDOR
Manufacturer Part Number: VENM3542
IMS Product Code: 1803244
Packaging: Sold Individually

Description:

Baldor VENM3542 General Purpose Motor

Specifications:

  • Motor phase: 3 ph
  • Overall length (c-dimension): 11.06 in
  • Motor horsepower: 0.75 hp, 3/4 hp
  • Service factor: 1.15
  • Synchronous rpm: 1800 rpm
  • Frame material: Steel
  • Motor supply voltage: 230/460 V
  • Insulation class: F
  • Frame size: 56C
  • Ip rating: 44
  • Enclosure type: TENV (Totally Enclosed Non-Ventilated)
  • Standards met: NEMA-C
  • Frequency rating: 60 Hz
  • Harmonization code: 8501.51.4040
  • Mounting type: Footless/C-Face Flange
  • Weight: 33 lbs
  • Duty / condition type: Continuous Duty
  • Amps @ voltage: 2.5 A @ 208 V; 2.3 A @ 230 V; 1.1 A @ 460 V
  • Mounting type: Footless/C-Face Flange
  • Full load current: 1.1
  • Full load efficiency: 84 %
  • Volts @ frequency: 230 V @ 60 Hz; 460 V @ 60 Hz
  • Shaft diameter: 5/8" in

Request A Quote
Let us know your requirements and an IMS Supply representative will provide you with a detailed quote.

Shipping Times Provided In Quote

Product images shown are for illustration purposes only and may not be an exact representation of the product you will receive. IMS Supply is not an authorized distributor, reseller or representative of Baldor. All product names, trademarks, brands and logos used on this site are the property of their respective owners and are used for identification purposes only.
