BALLUFF BES M18MD-PSC12E-S04G INDUCTIVE SENSOR
Quick Overview
Manufactured By: BALLUFF
Manufacturer Part Number: BES M18MD-PSC12E-S04G
IMS Product Code: 1937682
Packaging: Sold Individually
Description:
Balluff BES M18MD-PSC12E-S04G Inductive Sensor
Inductive sensor
Specifications
- Type: Inductive sensor
- Output: PNP
- Switching Function: Normally open (NO)
- Rated Operating Distance Sn: 12 mm
- Assured Operating Distance Sa: 9.7 mm
- Connection Type: Connector, M12x1-S04
- Operating Voltage UB max. DC: 30 V
- Operating Voltage UB min. DC: 10 V
- Eff. operating current Ie: 200 mA
- Switching freq. f max. (at Ue): 2500 Hz
- Voltage drop static max.: 2.5 V
- Ambient temperature Ta max.: 70 degrees C
- Ambient temperature Ta min.: -25 degrees C
- Enclosure Type per IEC 60529: IP67
- Protection Class: II
- Short circuit protected: Yes
- Polarity reversal protected: Yes
- Magnetic field immune: immune to magnetic DC and AC fields
- Housing material: CuZn
- Sensing face material: LCP + PTFE
- Surface protection: Nickel-plated
- Tightening torque: 35 Nm
- Mech. installation condition: Non embeddable
- Diameter d1: M18x1
- Depth: 50 mm
- Mounting length: 25.5 mm
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 4 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
