BANNER MQDC-415-RA CORDSET
Quick Overview
Manufactured By: BANNER
Manufacturer Part Number: MQDC-415-RA
IMS Product Code: 1778627
Packaging: Sold Individually
Description:
Banner MQDC-415-RA Cordset
M12 Single-Ended Cordset with 4-pin Right-Angle Female Connector and Flying Leads
Specifications
- Cable Jacket Material: PVC
- Connector 1 Key Code: A
- Coupling Nut Material: Nickel Plated Brass
- Cordset Length (m): 5.00
- Cordset Length Range (m): 5.00-9.99
- Connector 1 Gender: Female
- Connector 1 Orientation: Right Angle
- Outside Cable Diameter (mm): 5.21
- Connector 1 Number of Contacts: 4
- Number of Ends: Single Ended
- Connector 1 Type: M12
- Connector 2 Type: Flying Leads
- Overmold Material and Color: PUR Black
- Shield/No Shield: No Shield
- Minimum Temp. (Celsius): -40
- Maximum Temp. (Celsius): 70
- Current Rating (A): 4.0
- Voltage Rating (V): 250 V ac/dc
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 9 hours and 2 minutes.
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 2 In Stock
Ships today if ordered in the next 9 hours and 2 minutes.
