Quick Overview

Manufactured By: BANSBACH
Manufacturer Part Number: GS-40-160-B123
IMS Product Code: 1735471
Packaging: Sold Individually


Force range: 112 lbs to 1,124 lbs (compressed up to 1,675 lbs)
Stroke: 3.94" to 39.37"
Piston rod diameter: Ø 0.79"
Progression: Approx. 37 % to 49 %
Lifetime: Approx. 250,000 cycles
Operating temperature range: -4 °F to +176 °F
Material Outer body: Steel coated with UV paint; Piston rod: Steel with wear-resistant coating; End fittings: Zinc plated steel
Operating fluid: Nitrogen gas and oil
Mounting: In any position. Hint: We recommend mounting with piston rod downwards to take advantage of the built-in end position damping.
End position damping length: Approx. 1.18" to 2.76" (depending on the stroke)
Positive stop: External positive stop at the end of stroke provided by the customer.
Application field: Hoods, Shutters, Machine housing, Conveyor systems, Control boxes, Furniture industry, Jacking applications, Assembly stations, Vehicle technology
