BROWNING VPS-232 PILLOW BLOCK BALL BEARING
Quick Overview
Manufactured By: BROWNING
Manufacturer Part Number: VPS-232
IMS Product Code: 1800590
Packaging: Sold Individually
Description:
Browning VPS-232 Pillow Block Ball Bearing
Pillow Block Ball Bearing Unit - 2-Bolt Base, 2 in Bore, Cast Iron Material, Standard Duty, Non-Expansion Bearing (Fixed)
Specifications
- Mounting Type: 2-Bolt Base
- Bore Type: Straight
- Bore Diameter: 2 in
- Bolt Center To Center Length: 6.4380 to 7.4380 in
- Base To Bore Centerline: 2.5000 in
- Duty Type: Standard Duty
- Locking Device: Set Screw
- Seal Type: Single Lip Contact with Flinger
- Housing Material: Cast Iron
- Expansion Type: Non-Expansion Bearing (Fixed)
- Overall Height: 4.9690 in
- Overall Length: 8.8130 in
- Base Width: 2.3130 in
- Finish Coating: Gray Paint
- Bolt Size: 0.6250 in
- Insert Material: 52100 Bearing Steel, Black Oxided Inner
- Max Operating Temperature: 200 °F
- Radial Dynamic Load Capacity: 9752 lbf
- Radial Static Load Capacity: 6601 lbf
- Max Rpm: 2500 rpm
- Lubrication Type: Lithium Complex NLGI 2 Grease
- Series: Normal
- Replacement Bearing: VS-232
- Misalignment Angle: ±1.5° Misalignment - Static Only
- Type Of Bearing: Ball Bearing
- Weight: 8.53 lbs
- Number Of Mounting Holes: 2
- Overall Width: 2.31 in
- Foot Height: 1.00 in
- Bolt Spacing: 6.94 in
- Centerline to Outermost Bearing Face: 1.406 in
- Rolling Element: Ball Bearing
- Housing Base: Semi-Solid
- Bore Shape: Straight
- Housing Construction: One Piece
- Outer Ring Land Profile: Standard
- Cage Material: Molded fiber glass reinforced nylon
- Housing Type: Pillow Block, Two Bolt
- Slot Length: 1.22 in
- Housing Style: Pillow Block
- Ability to Relubricate: Yes
- Cage Type: Ball Riding Retainer
- Grease Fitting Thread Size: 1/8 NPT
- Radial Clearance: Standard
- Maximum Speed: 2500 rpm
- Bearing Insert Finish: Black Oxide Coated Inner Ring
- Base Length: 8.88 in
- Dynamic Load Rating: 9,752 lb
- Inner Ring Outside Diameter: 2.749 in
- Shaft Locking Type: Set Screw
- Size Code: 211
- Fixed vs. Expansion: Fixed
- Misalignment Capability: ±2.0° Misalignment - Static Only
- Static Load Rating: 6,570 lb
- Country of Origin: Mexico
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 2 In Stock
Ships today if ordered in the next 4 hours and 43 minutes.
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 5 hours and 43 minutes.
