BUSSMANN LP-CC-12 TIME DELAY FUSE
Quick Overview
Manufactured By: BUSSMANN
Manufacturer Part Number: LP-CC-12
IMS Product Code: 2149736
Packaging: Box of 10
Sold Individually
Box of 2
Box of 10
Description:
Bussmann LP-CC-12 Time Delay Fuse
Class CC, Time Delay Fuse, 12A, 600V AC, 150V DC, Dual Element, Melamine Body, 13/32 in x 1-1/2 in
Specifications
- ampere rating: 12
- voltage rating ac: 600
- voltage rating dc: 150
- class: cc
- type: time delay
- element: dual element
- interrupting rating ac: 200,000 aic rms
- interrupting rating dc: 20,000 aic
- physical size: 0.41" x 1.5"
- body material: melamine
- fuse body style: cylindrical
- fuse class or type: cc
- fuse diameter x length: 13/32 in x 1-1/2 in
- overall diameter: 13/32 in
- overall length: 1-1/2 in
- speed: time-delay
- standards: ce/ul-248-4 guide jddz/csa class 1422-02
- visual indication: non-indicating
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
