CAMDEN CX-EPD1289L SURFACE MOUNT GRADE 1 RIM STRIKE
Quick Overview
Manufactured By: CAMDEN DOOR CONTROLS
Manufacturer Part Number: CX-EPD1289L
IMS Product Code: 2143764
Packaging: Sold Individually
Description:
Camden CX-EPD1289L Surface Mount Grade 1 Rim Strike
Electric rim strike with preload for use with exit devices. Surface-mounted design for hollow metal, aluminum, and wood frames. Accommodates up to 3/4" latch projection. Features 12/24V AC/DC operation, fail-safe/fail-secure modes, and built-in latch monitoring.
Specifications
- Dimensions: 9-1/8"L x 1-7/8"W x 3/4"D (231.6mm x 48mm x 19.8mm)
- Voltage: 12/24V AC/DC
- Current Draw: 560mA @12V DC, 280mA @24V DC
- Static Holding Force: 1,500 lbs
- Preload: 15 lbs
- Dynamic Strength: 70 ft-lbs
- Endurance: 1,000,000 Cycles (Factory Tested), 250,000 Cycles (UL Verified)
- Mode: Field Selectable Fail Safe or Fail Secure
- Operation: AC Buzz, DC Silent
- Duty: Continuous
- Latch Monitor: SPDT, 100mA @24V DC, Resistive
- Material: Tamper resistant stainless steel
- Certifications: UL Security Listed Grade 1, UL 1034 Burglary Listed, UL10C/CAN4-S104 3 hour fire rated
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 2 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
