CANTEC SYSTEMS CHFC-3 24V 50A BATTERY CHARGER
Quick Overview
Manufactured By: CANTEC SYSTEMS
Manufacturer Part Number: CHFC-3
IMS Product Code: 2130569
Packaging: Sold Individually
Description:
Cantec Systems CHFC-3 24V 50A Battery Charger
High frequency battery charger designed to provide safety and reliable charging
Specifications
- Input Voltage: 115VAC ± 10%
- Input Current: 20 A
- Input Frequency: 50-60 Hz
- Efficiency: >85 %
- Power Factor: 0.68
- Absorbed Maximum Current: 17 A
- Inrush Current: <2.7 A
- Absorbed Minimum Power: <5 W
- Absorbed Maximum Power: 3 kW
- Constant Output Voltage: 24V
- Output Current: 50A
- Temperature Compensation: -5 mV/°C
- Temperature Sensor: -20 to +50 °C
- Output Voltage Ripple: <1 %
- Humidity: 90%
- Switching Frequency: 50 ± 5% kHz
- Phase: single phase
- Isolation Input-Case: 500 VDC
- Isolation Input-Output: 1250 VAC
- Isolation Output-Case: 500 VDC
- Leakage Current: <3 mA
- Input Fuse: 25 A
- Output Fuse: 125 A
- Thermal Alarm Temperature: 100 °C
- Length: 43 CM
- Width: 22 CM
- Height: 11 CM
- Weight: 5.5 KG
- Supply Voltage: 230 ± 10% Veff
- Operating range of temperature: -20 to +50 °C
- Maximum relative humidity: 85%
- LED Indicator: RED (initial charging phase), YELLOW (80% charge), GREEN (100% charge)
- Auxiliary Contacts: changeovers contacts 0,3A 125VAC 0,3A 110VDC 1A 30VDC
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
