CKD SC3U-10-8 SPEED CONTROLLER
Quick Overview
Manufactured By: CKD
Manufacturer Part Number: SC3U-10-8
IMS Product Code: 2122605
Packaging: Sold Individually
Description:
CKD SC3U-10-8 Speed Controller
Universal elbow type speed controller with push-in joint. Meter-out control method. Made of polybutylene terephthalate and polyetherimide. For compressed air systems.
Specifications
- Control Direction: configurable
- Pipe Connection: R3/8
- Tube Outer Diameter: 8mm
- Operating Pressure: 0.05-1.0 MPa
- Fluid: Compressed Air
- Fluid Temperature: 5-60 degrees C
- Ambient Temperature: 0-60 degrees C
- Flow Rate: 985 L/min (free flow), 950 L/min (controlled)
- Effective Area: 14.5 mm2 (free flow), 14 mm2 (controlled)
- Material: PBT, polyetherimide, brass, stainless steel, NBR
- Weight: 83g
- Country of Origin: Thailand
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
