COMPUTAR V1228-MPY 12MM F2.8 LENS
Quick Overview
Manufactured By: COMPUTAR LENS
Manufacturer Part Number: V1228-MPY
IMS Product Code: 2136794
Packaging: Sold Individually
Description:
Computar V1228-MPY 12mm F2.8 Lens
12mm F2.8 12 Megapixel C Mount Lens for machine vision and ITS applications
Specifications
- Focal Length: 12mm
- Megapixel: 12 Megapixel
- Mount Type: C Mount
- Format: 1.1"
- F-Number: F 2.8
- Pixel Size: 3.45µm
- Image Circle: Ø17.6
- Vibration Resistance: up to 5G
- Focus Control: Manual
- Iris Type: Manual Iris
- Max. Aperture Ratio: 1:2.8
- Max. Image Format: 14.2mm x 10.4mm(f 17.6mm)
- Operation Range: Iris: F2.8 - F16.0, Focus: 0.3m - Inf.
- Control: Iris: Manual, Focus: Manual
- Object Dimension at M.O.D.: 351.6 (H) mm x 257.0 (V) mm
- Angle of View: 1.1" H: 60.5°, D: 71.1°, V: 46.2°
- Operating Temperature: -10°C - +50°C
- Distortion: 1.1" -0.6% (y=8.8)
- Back Focal Length: 8.4mm
- Flange Back Length: 17.526mm
- Filter Size: M40.5 P=0.5mm
- Dimensions: f 42.0mm x 36.1mm
- Weight: 98 g
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 3 hours and 14 minutes.
