CRESTRON DM-NVX-352 4K60 AV ENCODER/DECODER
Quick Overview
Manufactured By: CRESTRON
Manufacturer Part Number: DM-NVX-352
IMS Product Code: 2130581
Packaging: Sold Individually
Description:
Crestron DM-NVX-352 4K60 AV Encoder/Decoder
Crestron DM-NVX-352 is a reliable, high-performance AV over IP encoder or decoder that transports 4K60 4:4:4 video over standard Gigabit Ethernet. It supports HDR10 and HDCP 2.2, with built-in scaling and video wall processing, USB and KVM routing, and Dante or AES67 audio capability.
Specifications
- Video Compression: JPEG 2000
- Video Resolutions: Up to 4096x2160@60Hz (DCI 4K60), 4:4:4 color sampling, HDR10 & Deep Color support
- Audio Formats: Primary multichannel (up to 8-channel LPCM or encoded HBR 7.1 surround sound), secondary 2-channel LPCM
- Bitrates: 200 to 950 Mbps
- Streaming Protocols: RTP, SRTSP, SDP
- Container: MPEG-2 transport stream (.ts)
- Session Initiation: Multicast via SRTSP
- Copy Protection: HDCP 2.2, AES-128, PKI
- Input Signal Types: HDMI w/HDR10, Deep Color, & 4K60 4:4:4 support
- Output Signal Types: HDMI w/HDR10, Deep Color, & 4K60 4:4:4 support
- Switcher: 3x1 in receiver mode (HDMI 1, HDMI 2, Stream), 2x1 in transmitter mode, manual or auto-switching, limited audio breakaway
- Scaler: 4K60 4:4:4 video scaler with motion-adaptive deinterlacing, intelligent frame rate conversion, Deep Color support, HDR10 support
- Digital Formats: Dolby Digital, Dolby TrueHD, Dolby Atmos, DTS, DTS ES, DTS 96/24, DTS HD High Res, DTS HD Master Audio, DTS:X, LPCM up to 8 channels
- Analog Formats: Stereo 2-Channel
- Analog-To-Digital Conversion: 24-bit 48 kHz
- Digital-To-Analog Conversion: 24-bit 48 kHz
- Ethernet: 10/100/1000 Mbps, auto-switching, auto-negotiating, auto-discovery
- USB: USB 2.0 host or device signal extension and routing
- RS-232: 2-way device control and monitoring up to 115.2k baud
- IR/Serial: 1-way device control via infrared up to 1.1 MHz or serial TTL/RS-232 (0-5 Volts) up to 19.2k baud
- HDMI: HDCP 2.2, EDID, CEC
- DM NVX (via Ethernet): HDCP 2.2, AES-128 AV content encryption with PKI authentication
- Power Consumption: 26 Watts typical
- Temperature: 32 to 104 degrees F (0 to 40 degrees C)
- Humidity: 10% to 90% RH (non-condensing)
- Heat Dissipation: 85 BTU/hr
- Acoustic Noise: 33 dBA maximum
- Dimensions: Height: 8.61 in (219 mm); Width: 9.27 in (236 mm); Depth: 1.50 in (39 mm)
- Weight: 2.0 lb (0.91 kg)
- Compliance: UL Listed for US & Canada, CE, IC, FCC Part 15 Class B digital device
