CRESTRON DM-NVX-E30 4K60 4:4:4 HDR NETWORK AV ENCODER
Quick Overview
Manufactured By: CRESTRON
Manufacturer Part Number: DM-NVX-E30
IMS Product Code: 2130580
Packaging: Sold Individually
Description:
Crestron DM-NVX-E30 4K60 4:4:4 HDR Network AV Encoder
Crestron DM-NVX-E30 is a compact AV over IP encoder designed to function as a transmitter. Featuring secure web-based control and management, an HDMI input, an analog audio output, AES67 transmit and receive capability, and copper Ethernet connectivity with PoE+ support, the DM-NVX-E30 offers a low-cost encoder solution for a DM NVX network AV installation of any size.
Specifications
- Manufacturer: Crestron
- Model: DM-NVX-E30
- Type: Network AV Encoder
- Video Resolution: 4K60 4:4:4
- HDR Support: HDR10, HDR10+, Dolby Vision
- Audio Support: 7.1 surround sound audio
- Ethernet Connectivity: Copper Ethernet with PoE+ support
- Control Options: RS-232, IR, CEC
- Bit Rate Options: Fixed, adaptive, or variable bit rate
- Stream Type: Pixel Perfect Processing (default) or DM-NVX-D10/D20/D200 Series
- Video Resolutions: Up to 4096x2160@60Hz (DCI 4K60), 4:4:4 color sampling, HDR10, HDR10+, Dolby Vision, and Deep Color support
- Audio Formats: Multichannel (up to 8-channel LPCM or encoded HBR 7.1 surround sound)
- Bit Rates: Fixed: 200 to 950 Mbps - user specified, Adaptive: Dependent on input resolution of the stream, or Variable: Less than 150 Mbps to maximum of 750 Mbps, dependent on content and input resolution of the stream
- Streaming Protocols: RTP, SDP
- Container: MPEG-2 transport stream (.ts)
- Session Initiation: Multicast via secure RTSP
- Copy Protection: HDCP 2.3, AES-128, PKI
- Input Signal Types: HDMI with HDR10, HDR10+, Dolby Vision, Deep Color, and 4K60 4:4:4 support, 7 (Dual-Mode DisplayPort interface and DVI compatible)
- Digital Formats: Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS, DTS ES, DTS 96/24, DTS HD High Res, DTS HD Master Audio, DTS:X, LPCM up to 8 channels
- Analog Formats: Stereo 2-channel
- Digital-To-Analog Conversion: 24-bit 48 kHz
- AES67: 24-bit 48 kHz
- Analog Performance: Frequency Response: 20 Hz to 20 kHz ±0.5 dB, S/N Ratio: >95 dB 20 Hz to 20 kHz A-weighted, THD+N: <0.005% @ 1 kHz, Stereo Separation: >90 dB
- Analog Output Volume Adjustment: -80 to +20 dB
- Ethernet: 100/1000 Mbps, auto-switching, auto-negotiating, auto-discovery, full/half duplex, TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), IEEE 802.1X, IPv4 only or both IPv4 and IPv6, Active Directory authentication, variable Multicast TTL, HTTPS web browser setup and control, Crestron 3-Series or later control system integration
- USB: USB 2.0 computer console (for setup)
- RS-232: 2-way device control and monitoring up to 115.2k baud with hardware and software handshaking (via control system); computer console (for setup)
- IR/Serial: 1-way device control via infrared up to 1.1 MHz or serial TTL/RS-232 (0-5 V) up to 19.2k baud (via control system)
- HDMI: HDCP 2.3, EDID, CEC
- DM NVX (via Ethernet): HDCP 2.3, AES-128 AV content encryption with PKI authentication, RTP, secure RTSP, SDP, ONVIF, IGMPv2, IGMPv3, SMPTE 2022, FEC (Forward Error Correction)
- Ethernet Connector: (1) 8-pin RJ-45 connector, female; 100BASE-TX/1000BASE-T Ethernet port; PoE+ PD (powered device) port, IEEE 802.3at Type 2 PoE+ Class 4 (25.5 W) compliant
- HDMI INPUT: (1) HDMI Type A connector, female; HDMI digital video/audio input (DVI and Dual-Mode DisplayPort interface compatible)
- AUDIO: (1) 5-pin 3.5 mm detachable terminal block; Balanced/unbalanced stereo line-level audio output; Output Impedance: 200 Ohms balanced, 100 Ohms unbalanced; Maximum Output Level: 4 Vrms balanced, 2 Vrms unbalanced
- CONSOLE, USB: (1) Micro USB connector, female; USB 2.0 computer console port (for setup)
- IR 1 – 2: (1) 4-pin 3.5 mm detachable terminal block; Comprises (2) IR/Serial ports; IR output up to 1.1 MHz; 1-way serial TTL/RS-232 (0-5 V) up to 19200 baud; IRP2 emitter sold separately
- COM: (1) 5-pin 3.5 mm detachable terminal block; Bidirectional RS-232 port; Up to 115.2k baud, hardware and software handshaking support
- 24VDC 1.25A: (1) 2.1 x 5.5 mm DC power connector; 24 VDC power input; PW-2412WU power pack (sold separately)
- G: (1) 6-32 screw; Chassis ground lug
- NV: (1) Green LED, indicates unit is encoding (transmitting) network video
- OL: (1) Green LED, indicates an online connection to a control system via Ethernet
- Ethernet LEDs: (2) LEDs, green indicates Ethernet link status, amber indicates Ethernet activity
- HDMI INPUT LED: (1) Green LED, indicates sync detection at the HDMI input
- PWR: (1) Bi-color green/amber LED, indicates operating power supplied via PoE+ or optional power pack (sold separately), lights amber while booting and green when operating
- SETUP: (1) Red LED and (1) push button, displays onscreen IP address
- RESET: (1) Recessed push button, reboots the device
- PoE+: IEEE 802.3at Type 2 Class 4 (25.5 W) compliant; Compatible with Crestron DM-PSU-ULTRA-MIDSPAN, PoE+ compliant Ethernet switch, or approved third-party PSE
- Power Pack (Optional): Input: 0.8 A maximum @ 100-240 VAC, 50/60 Hz, Output: 1.25 A @ 24 VDC, Model: PW-2412WU (sold separately)
- Power Consumption: 15 W typical
- Temperature: 32 to 104 degrees F (0 to 40 degrees C)
- Humidity: 10% to 90% RH (non-condensing)
- Heat Dissipation: 48 BTU/hr
- Acoustic Noise: 33 dBA typical
- Chassis: Metal, black finish, integral mounting flanges, fan cooled; vented top, front, rear, and sides
- Mounting: Freestanding, surface mount, or attach to a single rack rail
- Height: 5.41 in. (138 mm)
- Width: 9.27 in. (236 mm)
- Depth: 1.15 in. (30 mm)
- Weight: 1.7 lb (0.77 kg)
