CRESTRON DMF-CI-8 8-SLOT CARD CHASSIS
Quick Overview
Manufactured By: CRESTRON
Manufacturer Part Number: DMF-CI-8
IMS Product Code: 2130749
Packaging: Sold Individually
Description:
Crestron DMF-CI-8 8-Slot Card Chassis
The Crestron DMF-CI-8 is a 2-space rack-mountable chassis designed to house up to eight Crestron DM-NVX-C or DMCF series cards. It features a metal chassis with black finish, vented sides, and fan cooling. The front panel includes a 2-inch diagonal LCD display, navigation pad, and various LEDs for status indication.
Specifications
- Card Slots: 8
- Power Consumption: 350 Watts fully loaded
- Dimensions: Height 3.47 in (89 mm), Width 17.40 in (442 mm); 19.00 in (483 mm) with rack ears, Depth 15.43 in (392 mm)
- Weight: 9.9 lb (4.5 kg) without cards
- Environmental: Temperature 32 to 104 degrees F (0 to 40 degrees C), Humidity 10% to 90% RH (non-condensing)
- Connectors: IEC 60320 C14 main power inlet, USB Type-A female, USB Type-B female, 8-pin RJ45 female
- Controls & Indicators: PWR LED, STATUS LED, LCD display, Nav Pad, HOME button, BACK button, CARD SLOT STATUS LEDs
