CRESTRON FT2-700-ELEC-B CABLE MANAGEMENT SYSTEM
Quick Overview
Manufactured By: CRESTRON
Manufacturer Part Number: FT2-700-ELEC-B
IMS Product Code: 2130768
Packaging: Sold Individually
Description:
Crestron FT2-700-ELEC-B Cable Management System
Crestron FT2 Series FlipTops revolutionize the media presentation experience by making it easier than ever to get connected at a meeting room table.
Specifications
- Brand: Crestron
- Type: Cable Cubby
- Model: FT2-700-ELEC-B
- MPN: 6509654
- Modules Spaces: 12 (2 rows of 6)
- Cable Pass-Through Plates: Accommodates up to 12 FT2A-PLT-PT series cable pass-through plate modules (8 are included)
- Cable Retractors: Accommodates up to 4 FT2A-CBLR-1T series one-touch cable retractors or FT2A-CBLR-GR series gravity cable retractors
- Connector Plates: Accommodates up to 12 FT2A-CP series connector plate modules
- Keystone Plates: Accommodates up to 12 FT2A-PLT-KEY series keystone plate modules
- USB Rapid Chargers: Accommodates up to 2 FT2A-CHGR-USBA/C USB rapid charging modules (maximum one per row)
- Blank Plates: Any unused module space can be filled with one FT2A-PLT-BLANK series blank plate module (4 are included)
- AC Power Outlet Modules: Accepts a variety of FT2A-PWR series AC power outlet modules
- Utility Shelves: Accommodates up to 2 FT2A-UTK-SHELF under-table utility shelves
- Connectors (on chassis): (2) 2.1 x 5.5 mm DC power connectors; 24 Volt DC power inputs
- Ground: (1) 6-32 screw; Chassis ground lug
- Controls: (1) Mechanical pushbutton; Disengages closed lid to actuate retraction
- Power Supply: Input: 1.5 Amps maximum @ 100-240 Volts AC, 50/60 Hz; Output: 2.5 Amps @ 24 Volts DC; Model: FT2A-UTK-PWS
- Utility Power: Dependent upon the AC power outlet module(s) installed
- Temperature: 32 to 112 degrees F (0 to 45 degrees C)
- Humidity: 10% to 90% RH (non-condensing)
- Chassis: Metal, black finish
- Cover: Metal, black or alloy finish, mechanically retracting lid, magnetically-attached bezel
- Mounting: Flush tabletop mount, fastened by four swiveling dogs, 1-3/4 in (44 mm) maximum surface thickness
- Height: 7.50 in (191 mm) with lid closed; 7.83 in (199 mm) with lid opened
- Width: 7.81 in (199 mm)
- Depth: 7.21 in (184 mm)
- Weight: 5.5 lb (2.5 kg) without power supply
- Compliance: UL Listed for US & Canada, CE
- Modular Design: Customizable connectivity solution
- Installation: Quick and simple tabletop installation
- Compatibility: Compatible with Crestron accessories
- Material: Machined metal surfaces
- Finish: Black or alloy
- Built-in Electrical Power Bus: Yes
- Module Slots: 12
- Lid Operation: One-touch lid
- Lid Feature: Retracts fully and disappears
- Mounting Surface Thickness: Up to 1 3/4 in. (44 mm)
