CRESTRON GLPP-1DIMFLV3CN-PM DIMMING MODULE
Quick Overview
Manufactured By: CRESTRON
Manufacturer Part Number: GLPP-1DIMFLV3CN-PM
IMS Product Code: 2151217
Packaging: Sold Individually
Description:
Crestron GLPP-1DIMFLV3CN-PM Dimming Module
Crestron Green Light Power Pack, 3-Channel 0-10V Dimmer w/Cresnet & Built-in Power Monitoring
Specifications
- Load Ratings: 16 Amps @ 100-277VAC, 50/60Hz (20 Amps, de-rated to 80%)
- Dim Load Types: 0-10 Volt fluorescent ballast (4-wire); 0-10V LED drivers; 60 mA max current sink
- Switch Load Types: Fluorescent Ballast, Incandescent, Magnetic Low-Voltage, Electronic Low-Voltage, Neon/Cold Cathode, High-Intensity Discharge
- Relay Lifetime: 1,000,000 cycles
- Power Consumption: 1.5 Watts @ 120-277V, with no sensors or keypads attached
- Main Power: 100-277 Volts AC, 50/60Hz
- Available Sensor Power: 2.5W @ 24 Volts DC
- Temperature: 32 to 104 degrees F (0 to 40 degrees C)
- Humidity: 10% to 90% RH (non-condensing)
- Height: 4.25 in (108 mm)
- Width: 8.63 in (219 mm); 9.88 in (251 mm) with antenna at 90 degree angle (wireless model only)
- Depth: 2 in (51 mm)
- Weight: 2 lb (907 g)
- Standards & Certifications: UL916, FCC, Title 24
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships on Monday, February 16, 2026
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
