CRESTRON M201923005 7 INCH TABLETOP TOUCH SCREEN
Quick Overview
Manufactured By: CRESTRON
Manufacturer Part Number: M201923005
IMS Product Code: 2130764
Packaging: Sold Individually
Description:
Crestron M201923005 7 Inch Tabletop Touch Screen
A stylish and versatile tabletop touch screen featuring web browsing, Crestron HTML5 and Smart Graphics software technology, custom-programmable icons, H.265/H.264 streaming video, a Rava SIP intercom, Wi-Fi network connectivity, and PoE+ (Power over Ethernet Plus) network power.
Specifications
- Aspect Ratio: 16:10 WXGA
- Audio Formats: AAC stereo
- Bitrates: Up to 25 Mbps (20 Mbps maximum recommended)
- Brightness: 350 nits (cd/m²)
- Color Depth: 24 bit, 16.7M colors
- Color: Black
- Connector: RJ-45, HDMI, USB
- Contrast: 850:1
- Depth: 4.37 in. (111 mm)
- Display Type: TFT active matrix color LCD
- Ethernet: 100 Mbps, auto switching, auto negotiating, auto discovery
- Hard Keys: (6) Virtual buttons in collapsible universal tool bar
- Height: 4.02 in. (102 mm)
- Heat Dissipation: 44 BTU/hr
- Housing: Plastic, smooth black or white finish, edge-to-edge glass with black or white surround
- Humidity: 10% to 95% RH (noncondensing)
- Illumination: Edgelit LED with auto brightness control
- Input Resolutions: Up to 1920x1080@30fps
- Intercom: Built-in Rava SIP intercom
- Maximum Project Size: 600 MB
- Power: IEEE 802.3at Type 2 compliant PoE+ PD (Powered Device)
- Programmable Buttons: Custom-programmable virtual control buttons
- Protocol: RTSP
- RAM: 2 GB LPDDR3
- Reset: (1) Pin hole on bottom for hardware reset
- Resolution: 1280 x 800 pixels
- Security: 64 and 128-bit WEP, WPA and WPA2-PSK with TKIP and AES
- Size: 7 in. (178 mm) diagonal
- Software Support: Crestron HTML5 and Smart Graphics software custom user projects
- Storage: 16 GB eMMC pSLC
- Temperature: 32 to 104°F (0 to 40°C)
- Touch Screen: Projected capacitive, 5-point multitouch capable
- Touch Screen Type: Capacitive
- Transceiver: IEEE 802.11a/b/g/n/ac Wi-Fi (2.4 or 5 GHz 2-way RF)
- USB: USB 2.0 host for room scheduling accessories
- Viewing Angle: ±80° horizontal, ±80° vertical
- Weight: 1.33 lb (605 g)
- Width: 6.87 in. (175 mm)
