DIXON GLS405 LIQUID FILLED STAINLESS STEEL GAUGE
Quick Overview
Manufactured By: DIXON VALVE
Manufacturer Part Number: GLS405
IMS Product Code: 1933027
Packaging: Sold Individually
Description:
Dixon GLS405 Liquid Filled Stainless Steel Gauge
Dixon Valve GLS405 is a liquid-filled pressure gauge with a stainless steel case and lower mount. It is designed for long service under rugged conditions and is suitable for applications on pumps, hydraulic and pneumatic systems, compressors, and machine tools. The gauge features a 2-1/2" face, 1/4" NPT brass connection, and is filled with glycerin.
Specifications
- Pressure Range: 0-30 PSI
- Size: 2-1/2" face
- Mount: 1/4" lower mount
- Material: 304 Stainless Steel case
- Temperature Range: -40°F to 150°F
- Weight: 0.52 lb
- Accuracy: ±3-2-3%
- Bourdon Tube Material: Copper alloy
- Dial Material: White aluminum
- Pointer Material: Black aluminum
- Connection: 1/4" NPT brass
- Fill: Glycerin filled
- Window Material: Polycarbonate
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 16 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
