DODGE P2B-SCM-300 BEARING PILLOW BLOCK

Call For Quote

Quick Overview

Manufactured By: DODGE
Manufacturer Part Number: P2B-SCM-300
IMS Product Code: 646716
Packaging: Sold Individually

Description:

BEARING PILLOW BLOCK 3IN BORE 2BOLT

  • DualGuard seal comprised of single lip seal and rubberized flinger standard
  • Interchangeable mounting dimensions with most competitive products
  • 65° set screw angle for greater holding power and ease of installation in confined areas
  • Anti-rotation prevents insert rotation associated with light or rotating loads/ high-speed applications
  • Plus or minus 2° static misalignment

Mounting: Two-Bolt Base
Bore Diameter: 3 in
Bore Type: Round
Base to Bore Centerline: 3-1/2 in
Duty Type: Medium Duty
Housing Material: Cast Iron
Locking Device: Set Screw
Seal Type: Contact/Lip
Expansion Type: Non-Expansion Bearing (Fixed)
Overall Length: 11-3/4 in
Overall Height: 6.97 in
Finish/Coating: Black Oxide
Overall Width: 2.38 in
Radial Dynamic Load Capacity: 17407 lb
Radial Static Load Capacity: 13102 lb
Base Width: 3 in
Bolt Center-to-Center Length: 8-1/2 to 9-1/2 in
Lubrication Type: Lubrication Fitting
Series: 216
Manufacturer Catalog Number: 126822
Standards Met: AFBMA, AGMA, ASMMA, BSA, CMA, ISO 9002 Certified, MPTA, PTDA, UL
