EBM PAPST W2S130-BM15-01 AC AXIAL FAN
Quick Overview
Manufactured By: EBM PAPST
Manufacturer Part Number: W2S130-BM15-01
IMS Product Code: 1924311
Packaging: Sold Individually
Description:
Ebm Papst W2S130-BM15-01 AC Axial Fan
115V AC axial fan with ball bearing and external rotor shaded pole motor. Circular frame, 172mm diameter, 55mm depth. Impedance protected against overloading. Black aluminum housing and black steel impeller. 2-lead wire connection.
Specifications
- Nominal Rated Voltage AC: 115V
- Fan Frame Type: Circular
- Fan Frame Size: 172mm
- External Depth: 55mm
- Bearing Type: Ball Bearing
- Air Flow - CFM: 250.1CFM
- Noise Rating: 62dBA
- Power Rating: 46W
- Rated Speed: 3050rpm
- Power Connection Type: 2 Lead Wires
- IP Rating: IP20
- Air Flow - m3/min: 7m�/min
- Product Range: W2S130 Series
- Type of fan: AC
- Kind of fan: axial
- Fan dimensions: 172x150x55mm
- Power consumption: 47W
- Current rating: 0.63A
- Kind of Bearing: ball
- Rotational rate/speed: 2700rpm
- Frequency: 50Hz
- Impeller material: metal
- Enclosure material: aluminium
- Insulation class: B
- Leads: leads x2
- Lead length: 0.33m
- Operating temperature: -25...50�C
- Wire size: 20AWG
- Kind of motor: 1-phase
- Protection class: I
- Supply voltage: 115V AC
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 10 In Stock
Ships today if ordered in the next 2 hours and 28 minutes.
New - Missing Box (Special):
Is missing the fan guard.
Availability: 1 In Stock
Ships today if ordered in the next 2 hours and 28 minutes.
