FAFNIR 211WDD RADIAL BALL BEARING
Quick Overview
Manufactured By: FAFNIR
Manufacturer Part Number: 211WDD
IMS Product Code: 1924715
Packaging: Sold Individually
Description:
Fafnir 211WDD Radial Ball Bearing
Radial ball bearing with straight bore, double shielded, single row non-fill slot design. Made of steel with uncoated finish. Suitable for radial and axial loads.
Specifications
- Bore Type: Straight
- Bore Diameter: 55 mm
- Outside Diameter: 100 mm
- Overall Width: 21 mm
- Closure Type: Double Shielded
- Row Type: Single Row Non-Fill Slot
- Internal Clearance: R
- Max Operating Temperature: 120 degrees C
- Min Operating Temperature: -50 degrees C
- Bearing Material: Steel
- Cage Material: Steel
- Max Rpm: 3870 rpm
- Radial Dynamic Load Capacity: 10800 lbf
- Radial Static Load Capacity: 6570 lbf
- Weight: 1.5 lbs
