FAG 3310-BD-2HRS-TVH DOUBLE ROW ANGULAR CONTACT BEARING
Quick Overview
Manufactured By: FAG
Manufacturer Part Number: 3310-BD-2HRS-TVH
IMS Product Code: 2139868
Packaging: Sold Individually
Description:
Fag 3310-BD-2HRS-TVH Double Row Angular Contact Bearing
Double row angular contact bearing with 50 mm bore, 110 mm OD, 44.45 mm width, open design, 30 degree contact angle, C0 internal clearance
Specifications
- Bore Type: Straight
- Bore Diameter: 50 mm
- Outside Diameter: 110 mm
- Overall Width: 44.45 mm
- Row Type: Double-Row Non-Fill Slot
- Closure Type: Open
- Snap Ring Included: Without Snap Ring
- Bearing Type: Angular Contact Bearings
- Contact Angle: 30 degrees
- Internal Clearance: C0
- Radial Dynamic Load Capacity: 93000 N
- Radial Static Load Capacity: 70000 N
- Operating Temperature Range: -30 to +150 degrees C
- Cage Material: Polyamide
- Max Rpm: 4900 rpm
- Fillet Radius: 2 mm
- Series: 33
- Material: 52100 Steel
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
