FAG 6024 DEEP GROOVE BALL BEARING
Quick Overview
Manufactured By: FAG
Manufacturer Part Number: 6024
IMS Product Code: 2125516
Packaging: Sold Individually
Description:
Fag 6024 Deep Groove Ball Bearing
Single row, open type, steel cage, 120mm ID, 180mm OD, 28mm width
Specifications
- Bore Type: Straight
- Bore Diameter: 120 mm
- Outside Diameter: 180 mm
- Overall Width: 28 mm
- Closure Type: Open
- Row Type: Single Row Non-Fill Slot
- Snap Ring Included: Without Snap Ring
- Internal Clearance: C0
- Operating Temperature Range: Maximum of +120 degrees C
- Precision Rating: ABEC 1 (ISO Class Normal)
- Seal Type: Open
- Finish Coating: Uncoated
- Cage Material: Steel
- Fillet Radius: 2 mm
- Max Rpm: 5000 rpm
- Standards Met: DIN 625-1
- Series: 60
- Radial Dynamic Load Capacity: 88000 N
- Radial Static Load Capacity: 77000 N
- Weight: 2.07 kg
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
