FANUC A06B-6087-H130 ALPHA POWER SUPPLY MODULE
Quick Overview
Manufactured By: FANUC
Manufacturer Part Number: A06B-6087-H130
IMS Product Code: 1914050
Packaging: Sold Individually
Description:
Fanuc A06B-6087-H130 Alpha Power Supply Module
This is an Alpha Series power supply module designed for CNC systems and servo drives, providing 35 kW output power with 200-230 VAC input voltage and 3-phase configuration.
Specifications
- type: Alpha Power Supply Module MDL PSM-30
- input voltage: 200-230 VAC
- frequency: 50/60 Hz
- phase: 3 Phase
- output power: 35 kW
- output voltage: 283-325 VDC
- rated current: 127 A
- efficiency: >95%
- operating temperature: 0-55 degrees C
- cooling method: Air Cooled
- protection features: Overload, Overcurrent, Overvoltage Protection
- mounting: Vertical/Wall-mounted
- weight: 11.34 kg
- series: Alpha Series
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 1 In Stock
Ships today if ordered in the next 39 minutes.
Used (Special):
is whole part
Availability: 1 In Stock
Ships today if ordered in the next 39 minutes.
