FESTO DFM-32-80-P-A-GF GUIDED DRIVE
Quick Overview
Manufactured By: FESTO
Manufacturer Part Number: DFM-32-80-P-A-GF
IMS Product Code: 2127742
Packaging: Sold Individually
Description:
Festo DFM-32-80-P-A-GF Guided Drive
Double-acting guided drive with a 32mm piston diameter and 80mm stroke. Four plain slide bearings provide high rigidity suitable for high loads. Compact aluminium construction is maintenance-free and resistant to torque and lateral forces.
Specifications
- Piston Diameter: 32 mm
- Stroke: 80 mm
- Operating Pressure: 0.15 - 10 bar
- Mode of Operation: Double-acting
- Operating Medium: Compressed air to ISO 8573-1:2010 [7:4:4]
- Corrosion Resistance Class: 1 - Low corrosion stress
- Cleanroom Class: Class 7 according to ISO 14644-1
- Max Speed: 0.8 m/s
- Theoretical Force at 0.6 MPa (Return Stroke): 415 N
- Theoretical Force at 0.6 MPa (Advance Stroke): 482 N
- Moving Mass: 1450 g
- Product Weight: 2808 g
- Ambient Temperature: -20 to 80 degrees C
- Pneumatic Connection: G1/8
- Dimensions: 179 x 110 x 49 mm
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 2 In Stock
Ships today if ordered in the next 14 hours and 2 minutes.
