GRUNDFOS MTC2-6/4 MULTISTAGE COOLANT PUMP
Quick Overview
Manufactured By: GRUNDFOS
Manufacturer Part Number: MTC2-6/4 A-WB-A-AQQV
IMS Product Code: 2147290
Packaging: Sold Individually
Description:
Grundfos MTC2-6/4 Multistage Coolant Pump
Multistage coolant condensate pump with 3/4" NPT connection, 6 stages, 1 HP, 208-230/460 Volt, 60 Hz, 3 Phase, 3445 RPM, TEFC PE motor enclosure, Viton shaft seal, 194 °F max operating temperature, 145 PSI max pressure, 13.2 GPM capacity.
Specifications
- Capacities (GPM): 13.2 GPM
- Connection Type: NPT
- Discharge (Inches): 3/4"
- Heads To (Feet): 118.1 Feet
- HP: 1
- Hz: 60
- Impeller Material: Stainless Steel
- Maximum Pressure (PSI): 145 psi
- Model Number: MTC2-6/4
- Motor Enclosure Type: TEFC PE - Totally Enclosed Fan Cooled (Premium Efficient)
- Number of Stages: 6
- Phase: 3 Ph (Three Phase)
- Seal Code: AQQV
- Shaft Seal Material: O-Ring w/Fixed Driver, SiC/SiC, FKM
- Speed (RPM): 3445 RPM (Rated)
- Voltage: 208/230/460
