HARTING 09330102601 HAN E 10-POS MALE INSERT
Quick Overview
Manufactured By: HARTING
Manufacturer Part Number: 09330102601
IMS Product Code: 1876356
Packaging: Sold Individually
Description:
Harting 09330102601 Han E 10-Pos Male Insert
Male screw terminal insert with 10 contacts for Harting Han E series connectors. Screw termination, 16A rated current, 500V rated voltage. Made of polycarbonate with silver-plated copper alloy contacts.
Specifications
- Series: Han E
- Number of Contacts: 10
- Gender: Male
- Termination Method: Screw termination
- Rated Current: 16 A
- Rated Voltage: 500 V
- Contact Material: Copper alloy
- Contact Surface: Silver plated
- Insulator Material: Polycarbonate
- Conductor Cross-Section: 0.75 ... 2.5 mm
- Tightening Torque: 0.5 Nm (Contact screw M3), 0.5 Nm (Fixing screws M3), 1.2 Nm (PE screw M4)
- Limiting Temperature: -40 ... +125 degrees C
- Mating Cycles: >= 500
- RoHS: compliant with exemption
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 53 minutes.
