More Views
HARTING HAN 10B SURFACE MOUNTED HOUSING
Quick Overview
Manufactured By: HARTING
Manufacturer Part Number: HAN 10B-ASG2-LB-K-M32
IMS Product Code: 2129556
Packaging: Sold Individually
Description:
Harting HAN 10B Surface Mounted Housing
Surface mounted housing with metal cover, high construction, single locking lever, 2xM32 lateral cable outlet, aluminium die-cast housing, powder-coated, dust grey RAL 7037, IP65 protection.
Specifications
- Series: Han 10B
- Type: Surface mounted housing
- Locking type: Single locking lever
- Cable outlet: 2xM32 lateral
- Dimensions: Length: 94.0 mm, Width: 57.0 mm, Height: 80.8 mm
- Mounting dimensions: Screw-on hole Number: 4, Diameter: 5.6 mm, Length: 82.0 mm, Width: 45.0 mm
- Temperature range: -40°C to 125°C
- Protection class: IP65
- Material: Housing: Aluminium die casting, Housing surface: powder-coated, Locking bracket: Polycarbonate + Stainless steel, Seal: Nitrile butadiene rubber (NBR)
- Colour: Dust grey RAL 7037
