HONEYWELL ML7421B1023 NON-SPRING RETURN VALVE ACTUATOR
Quick Overview
Manufactured By: HONEYWELL
Manufacturer Part Number: ML7421B1023
IMS Product Code: 2123980
Packaging: Sold Individually
Description:
Honeywell ML7421B1023 Non-Spring Return Valve Actuator
Non-spring return direct-coupled, linear-stroke, 24 volt valve actuator with 405 lbf stem force, modulating control signal, and 175-second drive timing.
Specifications
- Torque: 405 lbf
- Fail-Safe: Non-Spring Return
- Supply Voltage: 24 VAC
- Control Signal: Modulating 0-10 VDC
- Run Time: 175 s
- Stroke: 1.5 "
- Manual Operation: Yes
- Approvals: CSA, UL
- Power Consumption: 12 VA Rating
- Operating Temperature: 14 F To 122 F (-10 C To 50 C)
- Auxiliary Switches: Dual (24 VAC Use Only)
- Dimensions: 12 3/4 in. high x 7 in. wide x 7 in. deep
- Frequency: 50 Hz; 60 Hz
Used:
A previously used, fully functional product that may have some signs of cosmetic wear.
Availability: 1 In Stock
Ships Tomorrow
Emergency after hours shipping may be available.
Call (888) 437-6645 for more information.
