IDEC HA3K-2C1B SELECTOR SWITCH
Quick Overview
Manufactured By: IDEC
Manufacturer Part Number: HA3K-2C1B
IMS Product Code: 2152878
Packaging: Sold Individually
Description:
Idec HA3K-2C1B Selector Switch
2-position key-operated selector switch with SPDT contact configuration and solder-type tab terminals
Specifications
- Control Method: Selector switch
- Mounting Shape/Uses: Round hole 0.6 inch (16 mm)
- Body Shape: Separate type
- Operation: Heavy
- Mounting Hole Dimensions/Mounting Shape: f0.6 inch (16 mm)
- Control Part Shape (1): Key operation type
- Contact Configuration: 1c
- Contact Material: Gold contact
- Terminal Shape: Tab terminal type for soldering
- Protective Structure: IP65
- Notches: 2
- Notch Angle: 90 degrees
- Operating Method: Stops each position
- Key-Out Specification: Left side opening
