IDEC HW1B-M110Y PUSHBUTTON SWITCH
Quick Overview
Manufactured By: IDEC
Manufacturer Part Number: HW1B-M110Y
IMS Product Code: 1789171
Packaging: Sold Individually
Description:
Idec HW1B-M110Y Pushbutton Switch
Yellow momentary pushbutton switch with 1NO contact, 22mm mounting, M3.5 screw terminal
Specifications
- Button Type: Round
- Button Color: Yellow
- Degree of Protection: IP65
- Terminal Shape: M3.5 Screw Terminal
- Operating System: Momentary
- Contact Configuration: 1A
- Contact Material: Silver
- Mounting Hole Size: 22mm
- Size: 22 mm
- Component: Push Button
- Illuminated: No
- Operation: Momentary
- Mounting: 22 mm
- Contacts: 1NO
- Max Voltage: 600 VAC, 600 VDC
- Current Rating: 10 A
- Bezel: Plastic Round
- Lens/Button Shape: Round Flush
- Operator Color: Yellow
- Terminal Type: Spring-Up Screw
- Protection Rating: IP65
- NEMA Rating: NEMA 1, NEMA 12, NEMA 13, NEMA 2, NEMA 3, NEMA 3R, NEMA 4, NEMA 4X, NEMA 5, NEMA 3S
- Approvals: CE, CSA, UL
- Series: HW series
New - Open Box:
A new, unused item with no signs of wear. The item has its original packaging but it is not sealed.
Availability: 1 In Stock
Ships today if ordered in the next 14 hours and 33 minutes.
