IFM EFECTOR OPU203 PHOTOELECTRIC FORK SENSOR
Quick Overview
Manufactured By: IFM EFECTOR
Manufacturer Part Number: OPU203
IMS Product Code: 1938040
Packaging: Sold Individually
Description:
IFM Efector OPU203 Photoelectric Fork Sensor
A photoelectric fork sensor with IO-Link communication, PNP output, and red light emission.
Specifications
- Operating voltage: 10...30 DC
- Current consumption: < 30 mA
- Protection class: III
- Reverse polarity protection: yes
- Wave length: 660 nm
- Output function: light-on/dark-on mode
- Max. voltage drop switching output DC: 1 V
- Permanent current rating of switching output DC: 100 mA
- Switching frequency DC: 5000 Hz
- Short-circuit protection: yes
- Overload protection: yes
- Diameter of the smallest detectable object: 0.3 mm
- Communication interface: IO-Link
- Transmission type: COM2 (38,4 kBaud)
- IO-Link revision: 1.1
- SDCI standard: IEC 61131-9
- Ambient temperature: -25...60 degrees C
- Protection: IP 67
- EMC: EN 60947-5-2
- MTTF: 709 years
- Weight: 122 g
- Dimensions: 70 x 10 x 80 mm
- Fork depth: 55 mm
- Fork width: 50 mm
- Material: housing: diecast zinc black anodized; lens: glass
