IFM OG0030 THROUGH-BEAM SENSOR TRANSMITTER
Quick Overview
Manufactured By: IFM
Manufacturer Part Number: OG0030
IMS Product Code: 1845260
Packaging: Sold Individually
Description:
Ifm OG0030 Through-Beam Sensor Transmitter
Cylindrical photoelectric sensor transmitter with infrared LED light source, 18 mm diameter, 86 mm length, and 3-pin 1/2 in. male connector. Operates at 20-250V AC/DC, with a sensing distance of up to 15 meters.
Specifications
- Body Material: PBT
- Circuit Type: AC
- Diameter: 18 mm
- Dimensions: M18 x 1 / L = 76
- Electrical Connection: 3-Pin 1/2 in. Male Connector
- Frequency AC: 47...63 Hz
- Light Source: Infrared LED
- Operating Temperature Range: -25 to 80 degrees C
- Operating Voltage: 20...250 AC/DC
- Power Requirement: 20 to 250V AC/DC
- Protection: IP 67
- Sensing Method: Through Beam
- Style: Cylindrical
- Type of light: Infrared light
- Wave length: 880 nm
- Weight: 38 g
New:
A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).
Availability: 1 In Stock
Ships today if ordered in the next 4 hours and 30 minutes.
