IFM OGE700 THROUGH-BEAM SENSOR
Quick Overview
Manufactured By: IFM
Manufacturer Part Number: OGE700
IMS Product Code: 1937807
Packaging: Sold Individually
Sold Individually
Kit of 3
Description:
Ifm OGE700 Through-Beam Sensor
Through-beam sensor with PNP output and M12 connector
Specifications
- Operating voltage: 10...36 V DC
- Electrical design: PNP
- Output function: light-on/dark-on mode
- Type of light: red light
- Laser protection: Class 1
- Housing length: 72 mm
- Connection: M12 Connector
- Material: stainless steel (1.4404 / 316L); PA; LCP; EPDM; TPU
- Protection: IP 65, IP 67
- Ambient temperature: -10...60 °C
- Current consumption: 11 mA
- Protection class: II
- Reverse polarity protection: yes
- Wave length: 655 nm
- Typ. lifetime: 50000 h
- Max. voltage drop switching output DC: 2.5 V
- Permanent current rating of switching output DC: 200 mA
- Switching frequency DC: 1000 Hz
- Short-circuit protection: yes
- Type of short-circuit protection: yes (non-latching)
- Overload protection: yes
- Transmitter / receiver: receiver
- Range: < 60 m
- Factory setting: dark-on mode
- Range adjustable: yes
- Diameter of the smallest detectable object: 3 mm (at 60 m)
- MTTF: 786 years
- Weight: 61.9 g
- Dimensions: M18 x 1 / L = 72 mm
- Lens material: PMMA
- Display: 1 x LED, yellow
New - Missing Box:
A new, unused item with no signs of wear. The item may be missing the original packaging.
Availability: 9 In Stock
