IFM PN7292 DIGITAL PRESSURE SENSOR
Quick Overview
Manufactured By: IFM
Manufacturer Part Number: PN7292
IMS Product Code: 2140875
Packaging: Sold Individually
Description:
Ifm PN7292 Digital Pressure Sensor
Pressure sensor with display. Two switching outputs, one of them with IO-Link communication interface. Red/green display for clear identification of the acceptable range. The process connection can be rotated for optimum alignment. With long-term stability thanks to high overload protection. Robust design for use in harsh industrial environments.
Specifications
- Range: 0 to 1450 psi
- Power Required: 18 to 30V DC
- Process Connection: 1/4 in NPT
- Electrical Connection: 4 Pin M12 Connector
- IP Rating: IP65, IP67
- Housing Material: Stainless Steel
- Wetted Materials: Ceramic, Stainless Steel
- Burst Pressure: 9400 psi
- Circuit Type: PNP/NPN
- Output Current: 150mA, 200mA @ 60 Degrees C, 250mA @ 40 Degrees C
- Temp. Range: -13 Degrees to 176 Degrees F
- Compatible With: Air and Liquids
- Contact Form: SPST
- IO-Link Revision: 1.1
- Measuring Range: 0...100 bar 0...1450 psi 0...10 MPa
- Type of Pressure: relative pressure
- Output Signal: switching signal; IO-Link
